Product Parameter
Weight : 890kg
Digging bucket capacity : 0.02cbm/120kg
Rotation speed: 12RMP
Climbing capacity: 30°
Engine : Koop Engine 192
Main Valve : Beifang
Rated power : 10.2KW/2500RPM
Overall length / transport length A/M :4000/2380mm
Overall width B : 940mm
Overall height (cab roof) C : 2268mm
Total track width D : 930mm
Standard track plate width E :180mm
Track gauge F : 750mm
Wheelbase H : 884mm
Track ground length I : 962mm
Track length J : 1204mm
Minimum ground clearance K : 100mm
Tail swing radius L : 810mm
Max. Digging height : 2455mm
Max. Dumping height : 1605mm
Max. Digging depth : 1855 mm
Max. Digging radius on ground : 3050mm
Max. digging radius : 3130mm
